CA Sports Center, exteriorAI-assisted render
Sports centre · Surabaya

CA Sports Center

Status
Design complete
Scope
Architecture + Interior
Location
Surabaya
Year
2024

A sports hall under one black gable. The steel mesh skin wraps the court volume and sits on a concrete base that holds parking, a café and a store. Inside, the lift and stair cores are painted bright yellow, so the way up is easy to find from anywhere in the building.

CA Sports Center, exteriorAI-assisted render
ParkingAI-assisted render
Parking
Yellow lift lobbyAI-assisted render
Lift lobby
Stairwell seen from aboveAI-assisted render
Stairwell
Lift lobbyAI-assisted render
Lift lobby
CorridorAI-assisted render
Corridor
CaféAI-assisted render
Café
StoreAI-assisted render
Store
Washroom vanityAI-assisted render
Washroom
